Personnel
Transfer Basket
Make: Zainab'O'
Model: Z-601-6~8
Sailent Features
- Max. Load: 6~8 Adults - 680 KGS
- Luggage Weight; 320 KGS
- Rated Work Load: 1000 KGS
- Gross Weight: 285 KGS
- Max. Test Load: 2000 KGS
- (Shelf Life of Basket: 8 Years)
| Model | Capacity | Weight |
| Z-601-6~8 | 6~8 Persons | 628 LBS |
Quick & Effective
This 6~8 persons transfer device is used to quickly and effectively transport personnel on and off of platforms. Only the 4 person device come with netting between the riders.
Safety without Confinement
All models are equipped with quick release safety lanyards to provide safety and give the rider confidence while in transit. You told us you didn’t want to sit down and be buckled in. We listened.
Strong yet light Weight
Z-601-6~8 are made of a sturdy and very durable aluminum skeleton, to protect them from falling objects.
Safety comes First
The Z-601-6~8 is built above and beyond standard safety rules and regulations to provide a superior product to customers.
| ID. NO | DESCRIPTION |
| 1 | Master Oblong Lifting Ring |
| 2 | Bow Shackle Nut & Bolt |
| 3 | PVC Coated Yellow Cloth with Inner side safety nylon & shock absorb rubber |
| 4 | Wire Rope Lifting Sling |
| 5 | Master Link with Sub Link |
| 6 | Wire rope four-legged sling |
| 7 | Bow Shackle Nut & Bolt |
| 8 | Eye Bolt |
| 9 | Top Disc Powder Coated Yellow |
| 10 | Top & Bottom Disc Interconnecting Sling |
| 11 | Vertical pipe one side threaded |
| 12 | Vertical centre pipe handle (11&13) |
| 13 | Vertical pipe |
| 14 | Safety Sling for life jacket with SS Snap hook |
| 15 | Polyethylene Foam with Orange cloth & Eye Let |
| 16 | Bottom foot rubber |
| 17 | Bottom Disc Powder Coated |
| 18 | Nylon centre bush |
| 19 | Aluminium Ant-skid Chequered Plating |
| 20 | Safety Sling |
| 21 | Nylon Netting |
| 22 | Top Disc Polyethylene foam with orange cloth & wrapped with PP rope |
Basket Maintenance Chart
- 6 Months Inspection - Qualified Inspector/OEM
- 12 Months Load Test-OEM
- 18 Months Inspection-Qualified Inspector/OEM
- 24 Months Refurbishment-OEM
- 30 Months Inspection-Qualified Inspector/OEM
- 36 Months Load Test-OEM
- 42 Months Inspection-Qualified Inspector/OEM
- 48 Months Refurbishment-OEM
- 54 Months Inspection-Qualified Inspector/OEM
- 60 Months Load Test-OEM
- 66 Months Inspection-Qualified Inspector/OEM
- 72 Months Refurbishment-OEM
